Stainless Steel Sink Grinding Machine CNC Automatic Sink Edge Polishing Machine

Lugar de origen:

Porcelana

Nombre de la marca:

Hwashi

Certificación:

Éntrenos en contacto con

Pida una cita

Detalles del producto

Garantía:

1 año

Condición:

Nuevo

Grado automático:

Automático

Rango de corriente de soldadura:

50-200A

Velocidad de soldadura:

0.5-2m/min

Ancho del cinturón de abrasivo:

50 mm

Voltaje:

380V

Método de enfriamiento:

Enfriamiento de agua

Fuente de alimentación:

220V/50Hz

Potencia nominal:

80KVA

Corriente de salida:

Las demás:

Sistema de control:

SOCIEDAD ANÓNIMA

Pago y términos de envío

Cantidad de orden mínima

Precio

60000usd

Detalles de empaquetado

Película

Tiempo de entrega

60 días

Condiciones de pago

L/C, T/T

Capacidad de la fuente

5 pc/m

Productos relacionados

Vídeo

Máquina pulidora de acero inoxidable del borde automático del fregadero del CNC de la máquina de pulir del fregadero

Consiga el mejor precio

Vídeo

Máquina de soldadura por costura de capacidad nominal de 160KVA 50-200A para un diámetro de soldadura de 100 mm-1000 mm

Consiga el mejor precio

Vídeo

Máquina de rectificación y pulido de borde de fregadero Hwashi CNC

Consiga el mejor precio

Vídeo

Hwashi Wl-at-Pm1200 Máquina de rectificación automática de ruedas rodantes de fregadero, línea de producción de soldadura de tanques de agua

Consiga el mejor precio

Éntrenos en contacto con

+86-13380655800

export_trade@hwashi.com

86-752-3528326

Contacto ahora

Descripción de producto

Stainless Steel Sink Grinding Machine CNC Automatic Sink Edge Polishing Machine

Elevate your stainless steel sink manufacturing with our all-in-one Grinding and CNC Automatic Edge Polishing Machine – the ultimate solution for achieving flawless finishes, consistent quality, and streamlined production.

Designed for precision-driven workshops and large-scale manufacturing facilities, this advanced system combines powerful grinding capabilities with state-of-the-art CNC-controlled edge polishing, transforming raw stainless steel into showroom-ready sinks with unparalleled efficiency.

Why This Machine Redefines Sink Manufacturing:

CNC Precision, Perfect Consistency

Equipped with advanced computer numerical control (CNC) technology, the machine delivers exacting precision across every sink. From edge angles to surface smoothness, it eliminates human error, ensuring each unit meets strict quality standards – critical for luxury and commercial-grade sink production.

All-in-One Efficiency

Seamlessly integrates grinding and polishing into a single workflow. The high-torque grinding module removes imperfections, burrs, and weld marks, while the automatic edge polisher creates mirror-like or satin finishes (adjustable to your specifications). Reduce production time by up to 50% compared to manual processes.

Versatility for Every Sink Design

Adaptable to various sink shapes (undermount, drop-in, farmhouse), sizes, and thicknesses. Whether working with 304, 316, or other stainless steel grades, the machine’s customizable settings ensure optimal results for both standard and custom designs.

User-Friendly Operation

Intuitive touchscreen interface allows operators to program sink specifications, save presets for recurring orders, and monitor progress in real time. Minimal training is required, reducing onboarding time and operational errors.

Technical Data

Model	WL-AT-PM1200
Input Power	Three-phase 380V±10% 50Hz
Rated Capacity	10KVA
Grinding Wheel Diameter	50mm
Abrasive Belt Width	50mm
Abrasive Belt Rotating Speed	1400-2800mm/min (adjustable)
X Axle Moving Range	≥1220mm
Y Axle Moving Range	≥620mm
Z Axle Moving Range	≥250mm
A Axle Moving Range	360º
Rated Air Pressure	0.8MPa
Gas Consumption	1m3/h

MATERIAL CONFIGURATION:

1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price.

2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier.

3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery.

4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant.

5. Quick Delivery: Our company provides just-in-time delivery.

6. Prompt Response to Customers: Your satisfaction is the goal we pursue.
